7 Transport
26 100_0202_tr_0009.fm
Lift machine
1. Place the central lifting point in the vertical position.
2. To lift the motor, hang suitable tackle at the central lifting point.
3. Carefully load machine into or onto a stable means of transport.
4. After loading the machine, lash down the machine to prevent it from rolling off, slipping, or tipping
over. Attach tie-down lugs to the designated lashing points.
NOTICE
Appoint a specialist flagman for a safe lifting operation.
Item Designation Item Designation
1 Central lifting point (attachment point) 2 Tie-down lugs
