Wacker Neuson DT10

BA DT10 en - Edition 1.5 * dt10b610.fm 6-9
Technical data
6.18 Dimensions model DT10 with high-tip skip (option)
830
800
180
160
790
265
1
4
°
3931735
320 875 540
1294
8
3
°
2157
813
1111
1280
2758
1414
1711
Fig. 99: Vehicle dimensions (model DT10 with high tip skip)
Main data
Model DT10
Payload
550 kg
Dead weight incl. skip and loader unit
845 kg
Length
1735 mm
Width
790 mm
Height
1280 mm
Foothold projection
393 mm
Track width
180 mm
Chain length
875 mm
Front skip projection
320 mm
Skip load height (front edge)
1111 mm
Skip length
1294 mm
Skip width
800 mm
Skip depth
836 mm
Scraping depth
15 mm
