Wacker Neuson DT10

6-8 BA DT10 en - Edition 1.5 * * dt10b610.fm
Technical data
6.17 Dimensions model DT10 with high-tip skip (option)
1467
2610
868
1076
1134
268 875 540
3931684556
265
180
790
830
764
8
2
°
1
4
°
1688
1280
2009
160
442
Fig. 98: Vehicle dimensions (model DT10 with high tip skip)
Main data
Model DT10
Payload
550 kg
Dead weight incl. skip and loader unit
825 kg
Length
1684 mm
Width
790 mm
Height
1280 mm
Foothold projection
393 mm
Track width
180 mm
Chain length
875 mm
Front skip projection
268 mm
Skip load height (front edge)
1076 mm
Skip length
1134 mm
Skip width
764 mm
Skip depth
442 mm
Scraping depth
15 mm
