5-20 BA DT10 en - Edition 1.5 * * dt10b520.fm
Maintenance
Replacing the cartridge of hydraulic oil intake filter
Exchange filter cartridge A as follows:
☞Stop the engine
☞Remove the inspection flange by unscrewing screws B
☞Ensure that all dirt (dust) has been removed
☞Remove filter A by unscrewing it
☞Insert the new filter cartridge A
☞Retighten the inspection flange by screwing screws B
Collect the drained oil in a suitable container and dispose of it by an environmentally safe
manner!
Dispose of filter cartridge A in an environmentally friendly manner.
Fig. 87: Replace the oil intake filter cartridge
A
B
A
