Maintenance
Decreasing track tension
☞Park the dumper on firm and level ground
☞Raise the dumper with suitable means
☞Tracks should be raised off the ground
☞Stop the engine
☞Use additional supports for the dumper and ensure that it cannot overturn
☞Unscrew adjusting screw D with a suitable tool
➥Ram E is retracted
➥The track is loosened
☞Check track tension
➥Repeat the procedure if the tracks are too tight
Fig. 93: Loosen the chain
D
E
