8 Operation EH 6, EHB 7
40
8.2.5 Adjustable depth gauge (only EHB 7)
Adjusting the depth gauge
1. Press clamping piece.
2. Adjust depth gauge as needed by pulling out or pushing in.
3. Release clamping piece.
NOTICE
Slipping of the adjustable depth gauge can result in incorrect borehole depths.
f Always insert adjustable depth gauge into clamp with the grooved side
pointing up.
Item Designation
1 Adjustable depth gauge
2 Clamping piece
