Wacker Neuson EH 6

13 Technical data EH 6, EHB 7
54
13.2 EH 6/EHB 7 - 115
Total vibration value of the accel-
eration a
hv
*****
m/s
2
11.5 9 (chiseling)
13 (hammer
drilling in con-
crete)
Uncertainty K m/s
2
1.9 1.9 (chiseling)
1.5 (hammer
drilling)
* According to DIN EN 61140.
** According to DIN EN 60529.
*** Determined acc. to 2000/14/EC at ear of operator.
**** Determined according to 2000/14/EC.
*****According to EN 60745.
Designation Unit EH 6 M EHB 7 M
Item no. 0610306 0610307
Length x Width x Height mm (in) 473 x 109 x 293 (18.6 x 4.3 x 11.5)
Weight kg (lb) 7.1 (15.7) 7.3 (16.1)
Rated voltage V 110-120 1~
Rated frequency Hz 50
Rated power consumption W 1,300
Rated current consumption A 14
Percussion rate electronically
adjustable
rpm 2,200-2,850
Drill speed rpm - 300
Single stroke energy J 12
Tool holder SDS-max
Drive Universal electric motor with pro-
tective insulation
Class rating * II
Protection class ** IP2X
Sound pressure level L
PA
*** dB(A) 91 96
Designation Unit EH 6 M EHB 7 M
