OM ET18/20/24 us 1.3 * et18_20_24e300.fm 3-19
3
Meaning (option)
Check before starting the machine the operating pattern that has been
chosen. Label shows the lever position in which the ISO or SAE controls
are selected.
Position
At the left under the seat.
Meaning (option)
Indicates the control operations that do not comply with the ISO standard
if the SAE controls are selected.
Position
On the roof window on right-hand side in traveling direction.
Fig. 40: ISO/SAE changeover
Wiring diagram Controls
A ISO controls (Europe) Operating Pattern A
B SAE controls (US) Operating Pattern B
Fig. 41: SAE function label
