G 14 Initial Setup and Overview
wc_tx001185gb.fm 35
3.9 Emergency Stop Switch
Location
The emergency stop switch is activated by pressing the red button located at the
top of the right (control panel) side of the generator cabinet. The button can be
accessed with the panel doors closed. It is electrically isolated from the switch and
also from the metering panel.
Operation
Activate the emergency stop switch by pressing the red button.
Activating the emergency stop switch opens the main line circuit breaker and
the fuel solenoid and stops the engine.
The switch will remain activated until the button is pulled out.
NOTICE: Press the emergency stop button only in the case of an actual
emergency where the generator must be stopped immediately! In all other
instances, open the main line circuit breaker and then turn the engine start switch
to STOP.
wc_gr006203
