5A-19
50 HZ PORTABLE GENERATORS G3.3A/G4.6A/GS4.6A/GS5.7A 5A
Engine Wiring Schematic (G4.6A , GS4.6AModels)
1021SD67
OFF
ON
B
B
Y
B/R
G
18
11
12
1
2
3
4
4
5
2
5
1
6
3
W
R
Y
B
L/W
B
Y
L/W
R
W
G
T
13
11
14
15
16
12
17
10
G4.6 Models
GS4.6 Models
Wire Colors
B - Black
G - Green
L - Blue
P - Pink
R - Red
LL-Light blue
W- White
Y - Yellow
Br - Brown
Gr - Gray
Or - Orange
Pr - Purple
T - Tan
10 = Engine crank switch
11 = Oil level switch
12 = Coil
13 = Battery
14 = Charging coil
15 = Starter
16 = Starter solenoid
17 = 15 Amp fuse
18 = Ignition switch
