1A-13
G2.5A OPERATION 1A
1.23 Servicing Air Cleaner
The engine is equipped with a dual element air cleaner—
service frequently to prevent carburetor malfunction.
CAUTION: NEVER run engine without air cleaner.
Severe engine damage will occur.
e
d
1001SD13
1001SD12
1.24 Cleaning Sediment Cup
Turn fuel valve off. Remove sediment cup (e) and O-ring
(d). Wash them thoroughly in a nonflammable solvent.
Dry them and reinstall. Turn fuel valve on and check for
leaks.
a
c
b
1. Remove wing nut and air cleaner cover (a). Remove
both elements and inspect them for holes or tears.
Replace damaged elements.
2. Foam Element
(c)
Wash in solution of mild detergent and warm water.
Rinse thoroughly in clean water. Allow element to dry
thoroughly.
Soak element in clean engine oil and squeeze out
excess oil.
3. Paper element (b)
Tap element lightly to remove excess dirt or blow
compressed air through filter from the inside out.
Replace paper element if it appears heavily soiled.
NEVER use gasoline or other types of low flash
point solvents for cleaning the air cleaner. A fire or
explosion could result.
WARNING
!
