1A-5
G2.5A OPERATION 1A
Maximum Output W 2500
Continuous Output W 2250
Type Single voltage, single phase, brushless system
AC Voltages available volts phase 120 1ø
Frequency Hz 60
Power Factor 1.0
AC Receptacles
120V GFI duplex amp 15
120V duplex
amp 15
Main Circuit Breaker
amp 20
L x W x H in. (mm) 27 x 17.5 x 17 (685 x 445 x 435)
Weight (dry) lbs. (kg) 94 (43)
1.5 Technical Data
Generator
Engine
Engine Make Honda
Engine Model GX 160 K1VX
Power @ 3600 rpm Hp (kW) 5.5 (4.1)
Operating Speed - no load rpm 3700 ± 100
Operating Speed - full load rpm 3600 ± 100
Spark Plug NGK / ND BPR6ES / W20EPR-U
Electrode Gap in. (mm) 0.028 – 0.031 (0.7 – 0.8)
Fuel type Regular unleaded
Fuel Consumption qt. (l)/hr 1.8 (1.7)
Fuel Tank Capacity qt. (l) 3.9 (3.7)
Running Time hrs. 2.1
Air Cleaner type Dry type with oil-wetted foam pre-cleaner
Oil Capacity oz. (l) 1.2 (1.1)
Lubrication oil grade SAE 10W30 - service class SF, SE, SD or SC
Engine Lubrication
