GP Repair Maintenance
wc_tx000546gb.fm 57
4.22 Components—GP/GPS 5600A/6600A (rev. < 104)
Ref. Description Ref. Description
A Generator C Engine
B Control box D Electric start engines
Ref. Description Ref. Description
1 Main stator winding 1 11 Capacitor
2 Main stator winding 2 12 Engine ON / OFF switch
3 Auto idle unit 13 Rectifier
4 Main circuit breaker 14 Rotor winding/brushes
5 Voltage selector switch
(120/240V position shown)
15 Secondary (excitation) winding
6 GFI duplex receptacle—120V 16 DC winding
7 Twist-lock receptacle—120V 17 Automatic voltage regulator (AVR)
8 Twist-lock receptacle—120/240V 18 15A fuse (GPS only)
9 Auto idle switch 19 Ignition switch (GPS only)
10 5A fuse
Wire Colors
B Black R Red Y Yellow Or Orange
G Green T Tan Br Brown Pr Purple
L Blue V Violet Cl Clear Sh Shield
P Pink W White Gr Gray LL Light blue
To Next Page
