Technical Data GPi 1700
wc_td000354gb.fm
46
6.2 Generator Data
Machine GPi 1700
Machine
Generator type Multi-pole revolving field inverter
Generator speed rpm 3000–4200
Rated AC voltage V 120
Rated frequency Hz 60
Rated AC current A 11.3
Rated AC output KVA 1.35
Rated power factor 1.0
Rated DC voltage V 12
Rated DC current A 8.3
Safety device type Current breaker
Grounding system Neutral ground (Neutral bonded to
frame)
AC outlet receptacles 1 NEMA 5 20R
DC connection Screw-on terminals (+/–)
Length mm (in.) 490 (19.3)
Width mm (in.) 295 (11.6)
Height mm (in.) 445 (17.5)
Dry weight kg (lb) 20.5 (45.2)
