Operation RD 12A
24 wc_tx001071gb.fm
4 Operation
4.1 Features and Controls
See Graphic: wc_gr002946
Ref. Description Ref. Description
1 Air cleaner 24 Operator’s platform
2 Articulated joint 25 Engine oil filter
3 Hand holds 26 Rear drum fill/drain plug
4 Control panel 27 Rear drum—static
5 Dipstick 28 Scraper bar (4 places)
6 Drain hose—hydraulic tank 29 Sightglass—hydraulic tank
7 Drive motor 30 Sprinkler tube (2)
8 Drive pump 31 Steering wheel
9 Engine hood 32 Steering cylinder (under floor panel)
10 Vibration control button 33 Tiedown (2 places)
11 Exciter motor 34 Beacon light (optional)
12 Exciter/Steering pump 35 Battery (under floor panel)
13 Hydraulic filter—return line 36 Hydraulic suction line
14 Hydraulic strainer—suction line 37 Grease fitting—exciter (2 places)
15 Forward / Reverse control 38 Lifting eye (4 places)
16 Front drum—vibratory 39 ROPS
17 Fuel tank fill cap 40 Seat with seatbelt
18 Fuel filter 41 Water drain
19 Grease fittings—articulated joint (4
places)
42 Parking brake
20 Hydraulic tank fill port 43 Tow valve
21 Hydraulic manifold block 44 Choke lever
22 Water tank fill cap 45 Auxiliary battery positive terminal
23 Lockarm
