Operation RD 12A
42 wc_tx001071gb.fm
4.20 Emergency Shutdown Procedure
See Graphic: wc_gr001677
Activate the emergency stop switch (63) by pushing the red button in.
Pushing the emergency stop switch opens the main circuit breaker and
the fuel solenoid, and results in the engine shutting down. The switch
will remain activated until the button is pulled out.
NOTICE: PRESS THE EMERGENCY STOP BUTTON ONLY IN THE
CASE OF AN ACTUAL EMERGENCY WHERE THE MACHINE MUST
BE STOPPED IMMEDIATELY!
If a breakdown/accident occurs while the machine is operating, follow
the procedure below.
4.20.1 Activate the emergency stop switch.
4.20.2 Allow the engine and exhaust system to cool.
4.20.3 Using appropriate equipment, return the machine to an upright
position if tipped over.
4.20.4 Contact rental yard or machine owner.
53
47
54
61
50
62
55
wc_gr004114
56
63
