Lifting and Transporting CT 24-230E
18 wc_tx001520gb.fm
3 Lifting and Transporting
3.1 Lifting the Machine
See Graphic: wc_gr004390
NEVER lift the machine solely by the handle. The component may fail,
causing the machine to fall, possibly injuring bystanders.
See Technical Data for the weight of the machine.
To lift the machine manually:
3.1.1 Stop machine.
3.1.2 Obtain a partner and plan the lift.
3.1.3 Balance the weight between the partners and lift the machine by the
guard ring (a).
To reduce risk of back injury while lifting, keep your feet flat on ground
and shoulder width apart. Keep your head up and back straight.
To lift the machine mechanically:
3.1.4 Stop machine.
3.1.5 See Dimensions and Weight for weight of machine and be sure that
lifting device(s) can safely lift the weight.
3.1.6 Attach hook, harness, or cable to the lifting bracket (b) on machine as
shown and lift as desired.
Do not lift the trowel overhead with a float pan attached, as the pan
could fall off and strike personnel working in the vicinity.
WARNING
WARNING
WARNING
a
wc_gr004390
b
