CT 24-230E Lifting and Transporting
wc_tx001520gb.fm 19
3.2 Transporting
Required
• Transport vehicle capable of handling the weight of the trowel
• Suitable ropes or chains
Procedure
Follow the procedure below to tie down and transport the machine.
3.2.1 Lift the trowel onto the transport vehicle.
3.2.2 Position the handle so that it does not protrude outside the footprint of
the transport vehicle.
3.2.3 Connect the ropes/chains to the ring guard of the trowel as follows.
a. Connect them as low on the ring guard as possible to minimize
stress on the gearbox output shaft.
b. Use a crossing pattern as shown.
3.2.4 Connect the ropes/chains to the transport vehicle. Do not overtighten
them.
Result
The machine is now ready to be transported.
