Wacker Neuson Trowel CT 24-4A

Technical Data CT 24-4A
40 wc_td000219gb.fm
7 Technical Data
7.1 Dimensions and Weight
Dimensions mm (in.) Dry Weight kg (lbs.)
A 1537 (60-1/2) without float pan 64 (141)
B 610 (24) with float pan 70 (153)
C 1003 (39-1/2) Full Wet (Operating) Weight kg (lbs.)
D 940 (37) without float pan 66 (145)
E 788 (31) with float pan 71 (157)
C
C
E
E
D
D
A
A
B
B
wc_gr004383
