Technical Data WP 1550
wpm_td000333gb.fm 16
2.2 Plate Data
2.3 Sound and Vibration Specifications
Products are tested for sound pressure level in accordance with EN
ISO 11204. Sound power level is tested in accordance with European
Directive 2000/14/EC - Noise Emission in the Environment by
Equipment for use outdoors.
• The sound pressure level at operator’s location (L
pA
) = 97 dB(A).
• The guaranteed sound power level (L
WA
) = 108 dB(A).
Products are tested for hand/arm vibration (HAV) level in accordance
with ISO 5349, EN1033, and EN500-4 where applicable.
• HAV 10.8 m/s
2
WP 1550, WP 1550 W
0009325, 0009324, 0009548
Plate
Operating Weight
kg (lbs.)
88 (194)
Water Tank Capacity
l (qts.)
10.4 (11.0)
Exciter Speed
rpm / belt
5800 ± 100
Exciter Lubrication
ml (oz.)
150 (5)
Automatic Transmission Fluid
Dextron III / Mercon or equivalent
