Maintenance WP 1550
wpm_tx001126gb.fm 32
4.11 Lifting Machine
See Graphic: wpmgr006037
See Technical Data for the weight of the machine.
To lift machine manually:
4.11.1 Stop the engine.
4.11.2 Obtain help from a partner and plan the lift.
4.11.3 Grasp the machine by its cage (a) and lifting slot (b).
4.11.4 Lift the machine as shown.
To reduce risk of back injury while lifting, keep your feet flat on ground
and shoulder width apart. Keep your head up and back straight.
To lift machine mechanically:
NOTICE: Before attempting to lift, be sure that all lifting devices can
safely handle the weight of the machine. See Technical Data for the
weight of the machine.
4.11.1 Attach hook, harness, or cable to the machine as shown and lift as
desired.
NOTICE: DO NOT lift the vibroplate by its guide handle. The vibroplate
can shift, causing it to fall.
WARNING
a
b
wpmgr006037
