WACOM Intuos2 XD-0405-R User Manual

USING INTUOS2
Page 28
Contents
Index
USING THE SIDE SWITCH
The standard Intuos2 Pen is equipped with a DuoSwitch. This switch has two programmable functions
that can be selected by rocking the switch in either direction. You can use the DuoSwitch whenever the
pen tip is in Pro
ximity of the tablet. You do not have to touch the pen tip to the tablet in order to use the
switch.
To assign new switch functions, refer to Customizing Tool Buttons.
Double-Click Hint: Press the lower side switch
to double-click. This is easier than tapping
twice with the pen tip.
The upper switch position simulates
the CTRL key by default.
The lower switch position is set for a
double-click by default.
Important: The DuoSwitch on the Intuos2 Grip Pen can be removed if you do not need the switch functionality.
See DuoSwitch Removal and Installation for more information.

WACOM Intuos2 XD-0405-R Specifications

General

Brand	WACOM
Model	Intuos2 XD-0405-R
Category	Graphics Tablet
Language	English
