WAGNER 0558021 Operating Manual

20 ProSpray 3.25
GB
Appendix
Application Tip Spray Bore Spraying
marking angle inch / mm width mm
1)
Order no.
Natural paints 407 40° 0.007/0.18 160 0552407
Clear paints 507 50° 0.007/0.18 190 –––––––
Oils 209 20° 0.009/0.23 145 0552209
 309 30° 0.009/0.23 160 0552309
 409 40° 0.009/0.23 190 0552409
 509 50° 0.009/0.23 205 0552509
 609 60° 0.009/0.23 220 0552609
Synthetic-resin paints 111 10° 0.011/0.28 85 0552111
PVC paints 211 20° 0.011/0.28 95 0552211
 311 30° 0.011/0.28 125 0552311
 411 40° 0.011/0.28 195 0552411
 511 50° 0.011/0.28 215 0552511
 611 60° 0.011/0.28 265 0552611
Paints, primers 113 10° 0.013/0.33 100 0552113
Zinc chromate base 213 20° 0.013/0.33 110 0552213
Fillers 313 30° 0.013/0.33 135 0552313
 413 40° 0.013/0.33 200 0552413
 513 50° 0.013/0.33 245 0552513
 613 60° 0.013/0.33 275 0552613
 813 80° 0.013/0.33 305 0552813
Fillers 115 10° 0.015/0.38 90 0552115
Spray plasters 215 20° 0.015/0.38 100 0552215
Rust protection paints 315 30° 0.015/0.38 160 0552315
 415 40° 0.015/0.38 200 0552415
 515 50° 0.015/0.38 245 0552515
 615 60° 0.015/0.38 265 0552615
 715 70° 0.015/0.38 290 0552715
 815 80° 0.015/0.38 325 0552815
Spray plasters 217 20° 0.017/0.43 110 0552217
Rust protection paints 317 30° 0.017/0.43 150 0552317
Red lead 417 40° 0.017/0.43 180 0552417
Latex paints 517 50° 0.017/0.43 225 0552517
 617 60° 0.017/0.43 280 0552617
 717 70° 0.017/0.43 325 0552717
 219 20° 0.019/0.48 145 0552219
 319 30° 0.019/0.48 160 0552319
 419 40° 0.019/0.48 185 0552419
 519 50° 0.019/0.48 260 0552519
 619 60° 0.019/0.48 295 0552619
 719 70° 0.019/0.48 320 0552719
 819 80° 0.019/0.48 400 0552819
Mica paints 221 20° 0.021/0.53 145 0552221
Zinc dust paints 421 40° 0.021/0.53 190 0552421
Dispersions 521 50° 0.021/0.53 245 0552521
 621 60° 0.021/0.53 290 0552621
 821 80° 0.021/0.53 375 0552821
Rust protection paints 223 20° 0.023/0.58 155 0552223
 423 40° 0.023/0.58 180 0552423
 523 50° 0.023/0.58 245 0552523
 623 60° 0.023/0.58 275 0552623
 723 70° 0.023/0.58 325 0552723
 823 80° 0.023/0.58 345 0552823
Dispersions 225 20° 0.025/0.64 130 0552225
Binder, glue  425 40° 0.025/0.64 190 0552425
and ller paints 525 50° 0.025/0.64 230 0552525
 625 60° 0.025/0.64 250 0552625
 825 80° 0.025/0.64 295 0552825
 227 20° 0.027/0.69 160 0552227
 427 40° 0.027/0.69 180 0552427
 527 50° 0.027/0.69 200 0552527
 627 60° 0.027/0.69 265 0552627
 827 80° 0.027/0.69 340 0552827
 629 60° 0.029/0.75 285 0552629
 231 20° 0.031/0.79 155 0552231
 431 40° 0.031/0.79 185 0552431
 531 50° 0.031/0.79 220 0552531
 631 60° 0.031/0.79 270 0552631
 433 40° 0.033/0.83 220 0552433
 235 20° 0.035/0.90 160 0552235
 435 40° 0.035/0.90 195 0552435
 535 50° 0.035/0.90 235 0552535
 635 60° 0.035/0.90 295 0552635
 839 80° 0.039/0.99 480 –––––––
 243 20° 0.043/1.10 185 0552243
Large-area coatings 543 50° 0.043/1.10 340 0552543
 552 50° 0.052/1.30 350 0552552
1)Spraywidthatabout30cmtotheobjectand100bar(10MPa)pressurewithsynthetic-resinpaint20DINseconds.
12.4 Airless tip table
WAGNER without tip without tip
Trade Tip 2 Fthread(11/16-16UN) Gthread(7/8-14UN)
up to 270 bar for Wagner spray guns for Graco/Titan spray guns
(27 MPa) Order no. 0556 042 Order no. 0556 041
Spray gun lter “RED”Spray gun lter “WHITE”
Spray gun lter “YELLOW”Spray gun lter “GREEN”
Uncontrolled Copy
