ProSpray 3.25 27
Item Part No. Description
1 0290 230 Motor shroud
2 9800 340 Ground screw
3 0551 757 Transducer jumper
4 0290 225 Electronic cover
5 0290 229 Belly pan
6 9802 266 Screw (2)
7 0508 559 Screw (2)
8 0290 228 Door
9 0509 218 Screw (2)
10 0558 460 Plug*
11 ------- Strap*
12 9805 317 Screw (2)
13 0290 212 Handle cover, back
14 0290 213 Handle cover, front
15 ------- Drive assembly
16 0522 210 Mounting plate
17 9852 344 Fuse, 8A
18 0509 218 Screw (4)
19 0290 278 Face plate / oiler assembly
20 9804 916 Screw
21 0558 307A Control panel assembly, complete (includes items 30-37)
22 0509 218 Screw (4)
23 9805 348 Screw (4)
24 0509 636 Plug (2)
25 0558 298A Fluid section assembly
26 0290 205 Pusher assembly, stand and low boy cart models
0290 206 Pusher assembly, upright cart models
27 0508 553 Screw (2)
28 0508 559 Screw
29 0551 705 Siphon assembly, stand and low boy cart models
30 0290 227 Control panel cover with label
31 0507 749 Nutwithseal
32 0290 202 Set screw
33 0290 218 Knob
34 9850 936 Switch
35 0290 220 Digital Electronic Spray Control (DESC) display
36 0508 579 Potentiometer
37 0522 007 LED assembly
38 0508 549 Washer (2)
39 0508 550 Screw (2)
40 0508 551 Pail hook
41 0507 783 Clip
42 0290 224 Suction tube
43 0508 293 Retun tube
44 0509 218 Screw (4)*
45 0522 424 EMIlter,20A*
46 9800 340 Ground screw (2)*
47 0558 452 Bracket cover*
* Australia only
