Usabel materials
•
Internal emulsions
•
Paints
•
Acrylic paints
•
Glazes
•
Wood preservatives
•
Mordants
•
Primers
•
Wash primer
•
Plant protective agents
•
Under sealants
•
Hollow-space sealants
•
Disinfection agents
•
Oils
Unsuitable materials
•
Paints and lacquers containing heavily abrasive
components like outdoor emulsion / dispersion wall
paints
•
Silicate paints
•
Flammable materials
Field of application
Coating of interior walls as well as small and medium-
sized objects outdoors (e.g. garden fences, garage doors,
etc.).
Industrial use is excluded.
Technical data
Voltage 230V, 50 Hz
Power consumption 625 W
Protection class I
Maximum pressure 19.3 MPa (193 bar)
Flow rate at 140 bar (0 bar) 0.9 l/min (1,6 l/min)
Maximum temperature of coating
material
43°C
Sound pressure level*
Uncertainty
81 dBA
K= 4 db
Sound pressure output*
Uncertainty
94 dBA
K= 4 db
Oscillation level**
Uncertainty
< 2.5 m/s²
K = 1.5 m/s²
Maximum ambient temperature 40°C
Pump system piston pump
volume upper container, max. 7.5 l
Max. nozzle size L (0,017“)
Weight, ready to spray 10.5 kg
* Measured in accordance with EN 50144-2-7:2000
** Measured in accordance with EN 60745-1
Information about the oscillation level
The specied oscillation level has been measured according
to a standard test procedure and can be used to compare
against electric tools.
The oscillation level is also for determining an initial
assessment of the vibrational strain.
Attention! The vibration emission value can dier from
the specied value when the electric tool is actually in
use, depending on how the electric tool is being used. It is
necessary to specify safety measures to protect the operating
personnel. These measures are based on an estimated
shutdown during the actual conditions of use (all parts of
the operating cycle are taken into consideration here, for
example periods when the electric tool is switched o, and,
when it is switched on but running without any load).
