8.3 Spare parts list
GM 2000 EAC - EN
8.2
Item Part No. K Quantity Description
2 0179 354 1 Positioning bush
3 9900 962 1 Countersunk screw M3x12
4 0179 564 1 Data plate GM 2000 EAC R EN
4 0179 569 1 Data plate GM 2000 EAC F EN
5 9900 810 2 Flat head screw
6 9971 003 ❋ 1 O-ring green 6x1
7 0179 416 1 Air control knob
8 0179 396 ❋ 1 Trigger pin
9 0179 254 1 Valve stem assy.
10 0179 236 1 Valve ball
11 9971 182 ❋ 1 O-ring 4x1
12 0179 343 1 Thrust collar
13 0179 341 ❋ 1 Needle packing
14 0179 342 ❋ 1 Sealing screw
15 0179 340 1 Tappet cap
16 0179 395 ❋ 1 Seal
17 0179 339 1 Tappet seal
18 0179 338 ❋ 1 Air valve seal
19 0179 337 1 Valve tappet
20 0179 335 1 Valve stem
21 0179 394 1 Spring guide - valve stem
22 9994 247 1 Compression spring
23 0179 253 1 Adjuster for valve rod
24 9994 248 1 Compression spring
25 0179 488 1 Spring seat EAC/AC
26 0179 356 1 Tension nut
27 9994 627 1 Double nipple R1/4"
28 0128 510 ● 1 Air hose
30 0179 248 ● 1 Hose cover
31 9900 808 ❋ 1 Pan-head screw M3x8
32 0179 219 ❋ 1 Trigger
33 9995 611 ❋ 1 Cylinder filter 180 M
34 0179 383 1 Filter screw
35 0179 241 1 Paint connector
36 9984 481 ● 1 HP-hose DN4 - ND270 - M16x1.5 - 7.5 m
37 0179 643 1 Flat jet kit, 2000 EAC
38 0179 465 1 Cap ring 2000 EAC
39 0179 644 1 Air cap, 2000 EAC
40 0128 ... ● 1 AirCoat - flat tip (see chapter 7.2)
41 0179 485 1 Paint channel
42 0179 486 1 Seal screw
43 0179 452 1 Tip nut 2000 EAC
44 0132 724 ❋ 1 Round jet tip R15 (see chapter 7.1)
45 0132 351 1 R-Tip holder
46 0132 516 ❋ 1 Distributor
47 0179 642 1 Nozzle body 2000 EACR
48 0179 641 1 Nozzle set 2000 EACR
49 9994 269 1 Contact spring
50 0179 521 ● 1 Long filter housing
51 0043 590 ● 1 Compression spring
52 0128 389 ● 1 Seal
53 0128 347 ● 1 Hose connector M16x1.5
54 0179 160 ● 1 Long filter housing assembly
55 .... ... ● 1 Gun filter (see chapter 7.4.)
0179 926 ● 1 Paint channel assembly tool
0179 946 1 Set of seals EA/EAC/AC
