12
HERO 23D / Hero 23 / SF 23 Pro
ITEM ORDER NO. DESIGNATION
1 2369454 Inlet
2 2388291 Inlet valve housing
3 2369455 Clamp
4 2393043 Inlet valve assy. (incl. pos. 4)
5 2369458 Sealing ring
6 2383995
0340257
Pressure gauge assy. (China, Japan)
Pressure gauge assy. (AUS)
7 2369436 Reducing double nipple
8 2369586 Fitting
9 2393047 Pressure relief knob assy.
10 2369631 Pressure relief valve (incl. pos. 11)
11 9971395 O-ring
12 2393049 Sealing ring and locking screw
13 2393102 Outlet valve housing assy.
14 2393105 O-ring and sealing ring
15 2393106 Outlet valve assy. (incl. pos. 14)
16 9900217 Hexagon head screw
17 9920134 Washer
18 2369435 Paint head
19 2393137 Service kit paint head (pos 16-18)
20 2369432 Inlet
21 2369431 Diaphragm assy.
22 2393138 Service kit diaphragm (pos 20-21)
23 2369422 Pressure inlet
24 2337112 O-ring
25 2337113 O-ring
26 2393139 Service kit pressure inlet (Pos. 21-23)
27 2369425 Compression spring
28 3061423 Washer
29 2369424 Piston
30 2337078 Retaining ring
31 0252475 Pressure gauge assy. (CE)
4.1 SPARE PARTS HERO 23D, HERO 23, SF 23 PRO
4 SPARE PARTS
SPARE PARTS
GB
