WAGNER HERO 23D User Manual

3
HERO 23D / Hero 23 / SF 23 Pro
GB
CONTENTS
D
Contents
1 SAFETY REGULATIONS FOR AIRLESS SPRAYING 4
1.1 Flash point ___________________________________4
1.2 Explosion protection ___________________________4
1.3 Danger of explosion and re from sources of
ignition during spraying work ___________________4
1.4 Danger of injury from the spray jet _______________4
1.5 Secure spray gun against unintended operation ____4
1.6 Recoil of spray gun ____________________________4
1.7 Breathing equipment as protection against
solvent vapors ________________________________4
1.8 Prevention of occupational illnesses ______________4
1.9 Max. operating pressure ________________________5
1.10 High-pressure hose ___________________________5
1.11 Electrostatic charging
(formation of sparks or ames) __________________5
1.12 Use of units on building sites and workshops _______5
1.13 Ventilation when spraying in rooms ______________5
1.14 Suction installations ___________________________5
1.15 Earthing of the object __________________________5
1.16 Cleaning the unit with solvents __________________5
1.17 Cleaning the unit _____________________________5
1.18 Work or repairs at the electrical equipment ________5
1.19 Work at electrical components ___________________5
1.20 Setup on an uneven surface _____________________6
2 TECHNICAL DATA ___________________________ 6
3 REPAIRS AT THE UNIT _______________________ 7
3.1 Inlet valve ___________________________________8
3.2 Outlet valve __________________________________9
3.3 Pressure control valve __________________________9
3.4 Replacing the power cable ____________________ 10
3.5 Troubleshooting ____________________________ 11
4 SPARE PARTS ______________________________ 12
4.1 Spare parts list Hero 23D _____________________ 12
4.2 Spare parts list high-pressure lter (accessory) ____ 18
4.3 Spare parts list hopper _______________________ 18
4.4 Spare parts list trolley ________________________ 19
4.5 Spare parts list suction system _________________ 19
4.6 Spare parts list suction system Japan ___________ 20
ELECTRICAL REPAIR INSTRUCTIONS
1 BASIC PRINCIPLES ________________________ 21
1.1 Electrically instructed person __________________ 21
1.2 Skilled electrician for dened tasks _____________ 21
1.3 Legal foundations ___________________________ 21
1.4 Which tests must be performed ________________ 21
1.5 Five safety rules _____________________________ 22
1.6 Categorisation of protection classes ____________ 23
1.7 Explanation of electric variables and components _ 24
1.8 Explanation of electrical terms _________________ 24
2 FUNCTIONAL TEST WORK INSTRUCTIONS ____ 26
2.1 Functional test of cord set ____________________ 26
2.2 Functional test of capacitor ___________________ 26
2.3 Functional test of switches/buttons _____________ 27
2.4 Functional test of earthing contact socket _______ 27
2.5 Functional test of the motor overcurrent
protection switch ___________________________ 27
2.6 Functional test of the threephase motor _________ 28
2.7 Functional test of AC motor ___________________ 28
3 REPAIR WORK INSTRUCTIONS _______________ 28
3.1 Replacing a cord set _________________________ 28
3.2 Replacing a 400 V cord set ____________________ 29
3.3 Replacing the capacitor ______________________ 29
3.4 Replacing switches/buttons ___________________ 29
3.5 Replacing the earthing contact socket __________ 30
3.6 Replacing the motor protecting switch __________ 30
3.7 Replacing the threephase motor _______________ 30
3.8 Replacing the AC motor ______________________ 31
4 MACHINESPECIFIC DOCUMENTS ____________ 32
4.1 Connection diagram Hero 23D /SF 23 Pro _______ 32
4.2 Connection diagram Hero 23 (Japan) ___________ 33
4.3 Connection diagram Hero 23 (Taiwan) __________ 34

WAGNER HERO 23D Specifications

General

Brand	WAGNER
Model	HERO 23D
Category	Paint Sprayer
Language	English
