WAGNER HERO 23D User Manual

7
HERO 23D / Hero 23 / SF 23 Pro
TECHNICAL DATA
Japan
Voltage: 100 V
50 Hz
100 V
60 Hz
Fuses: 15 A time-lag
Unit connecting line : 6 m long, 3x2.0 mm²
Max. current consumption: 13.8 A
Degree of protection : IP 54
Rated input of device: 1.4 kW
Max. operating pressure : 21 MPa
Max. volume ow : 2.5 L/min 3.1 L/min
Volume ow at 12 MPa
(120 bar) with water : 2.3 L/min 2.7 L/min
Max. temperature of the
coating material : 43 °C
Max. viscosity : 20000 mPas
Empty weight : 29 kg
Hydraulic oil lling
quantity :
Hydraulics housing
Gears (grease)
1.3 Liter
45 g
Max. sound pressure level: 75 dB (A)*
*Place of measurement: 1 m distance from unit and 1.60 m
above oor, 12 MPa (120 bar) operating pressure, reverberant
oor
Taiwan
Voltage : 110 V AC, 60 Hz
Fuses : 16 A time-lag
Unit connecting line : 6 m long, 3 x 2 mm²
Max. current consumption: 11.0 A
Degree of protection : IP 54
Rated input of device: 1.3 kW
Max. operating pressure : 25 MPa (250 bar)
Max. volume ow : 3.2 l/min
Volume ow at 12 MPa
(120 bar) with water : 2.8 l/min
Max. temperature of the
coating material : 43 °C
Max. viscosity : 20,000 mPas
Empty weight : 27 kg
Hydraulic oil lling
quantity :
Hydraulics housing
Gears (grease)
1.3 liter
45 g
Max. vibration at the spraygun : lower than 2.5 m/s²
Max. sound pressure level: 75 dB (A)*
*Place of measurement: 1 m distance from unit and 1.60
m above oor, 12 MPa (120 bar) operating pressure,
reverberant oor
GB

WAGNER HERO 23D Specifications

General

Brand	WAGNER
Model	HERO 23D
Category	Paint Sprayer
Language	English
