English
5
Cup Mode
Setup
Start
English
Recommended for
small to medium jobs
Note: The cup will give you approximately 3-5
minutes of continuous spraying time depending
upon the cup size.
IMPORTANT: Avoid running the cup dry.
An empty cup will allow air to become
sucked into the sprayer, which leads to
globbing and spitting.
Note: Some of the graphics in this manual
may not exactly match your sprayer. All
information and instructions given in this
manual applies to all models except where
noted.
IMPORTANT: Always make sure the tip nut
is tightened securely prior to spraying.
1. Remove the cup -
Press and hold cup release
button.
2. Turn cup to release.
Remove cup.
3. Attach ll lid to the paint
container for easier pouring.
5. Replace the cup -
Line up the tabs / slots.
4. Fill the cup.
Note: Fill right up to, but do not
exceed, the MAX FILL line.
Note: The cup grip / cup handle
can be oriented on either side of
the sprayer, depending upon your
preference.
6. Turn cup to lock.
Note: The cup should “click” back
into place.
1
4
2
5
3
6
or
or
1
2
