5.6.2.2 VALVES 40 MPA; 400 BAR; 5800 PSI
Properties PV400-DN2.6-… DV400-DN2.6-… GA400PV-
DN2.6-…
GA400DV-
DN2.6-…
Maximum product pressure 40 MPa; 400 bar; 5802 psi
Control air pressure
0.5–0.8 MPa
5–8 bar
73–116 psi
Air pressure quality:
free from oil and water
Quality standard 7.5.4
according to ISO 8573.1,
2010
7: Particle concentration 5–10mg/m³
5: Humidity: pressure dew point ≤ +7 °C
4: Oil content ≤ 5mg/m
Product viscosity 20–2000 mPa·s
Product pH value 3.5–9 *
Product temperature
+5 °C … +80 °C
+41 °F … +176 °F
Maximum surface
temperature
+85 °C
+185 °F
Ambient
temperature
Operation
+5 °C … +40 °C
+41 °F … +104 °F
Assembly
0 °C … +40 °C
+32 °F … +104 °F
Storage
-20 °C … +60 °C
-4 °F … +140 °F
Relative humidity 10–95% (without condensation)
Maximum switching
frequency
3 Hz 3–5 Hz 3 Hz 3–5 Hz
Sound level < 65 dB(A)
Weight
1070g 1078g 547g 545 g
37.74 oz 38.03 oz 18.93 oz 19.22 oz
* Valve DV400-DN2.6-PTFE-TC-1.4404: check products for compatibility (see Chapter 5.6.1
