VERSION 06/2018
ORDER NUMBER DOC 2343275
Valves DV400-DN2.6-PTFE
Designation
SSt TC TC-1.4404
Order No. Order No. Order No.
1 1 Dosing valve DV400-DN2.6-PTFE 2342806 2342808 2370685
2 2 Piston 2330264
3 2 Hexagon nut 9913014
4 2 Pressure spring 400 bar; 40 MPa; 5802 psi 350482
5 2 O-ring 9974187
6 2 Valve rod, complete 2342838 384120 2371829
7 1 Valve housing ** ** **
8 2 Sealing screw 350485
9 2 Stop ring 2342203 2370229
10 4 Sealing ring at front 2342204
11 2 Support ring 2342205
12 2 Sealing collar 2342206
13 2 Sealing sleeve 2342207
14 4 Sealing ring at rear 2342208
15 2 Screw plug 104376
16 2 Plug 384323 2370230
17 2 Clamping nut 350490
18 2 O-ring 9974065
19 2 Male stud elbow 9992724
20 2 Hexagon screw 9907250
21 2 Hexagon nut 9913058
30 1 Loctite® 243
9992511
31 1 Mobil SHC Polyrex™ 222 grease
2342273
32 1 Mobilux® EP 2 grease
9998808
33 1 Loctite® 542
9992831
1 Service set 2342839 2342335 2371830
1 Seal set (scope of delivery, see Chapter 9.4) 2342336
= Wearing parts
= Included in service set.
= Not part of the standard equipment but available as a special accessory.
** = The valve housing can only be ordered from the WAGNER Service Department.
