SPRINT XE
Pos K Stk Order No. Designation
1 1 264268 Powder tank, 60 L
1 1 264224 Powder tank, 25 L
2 1 264215 Base housing
3 1 264381 Lid
4
1 264382 Fluidized bed
5 1.10 m 9971527 Foam rubber seal
6 6 9994703 Spring clip
7 12 9900717 Socket cap screw
8 1 9992270 Quick coupling for screw-on connector
9 1 184336 Hose tting
10 1 9910109 Hexagon nut
11 9982058 Exhaust hose, 17x3 mm
13 1 241372 Injector connection, complete
14 1 170533 Knurled nut
15 2 9920118 Washer
16 1 241276 Grounding cable, complete
17 12 9922102 Star washer
19 1 241376 Cable connection
20
1 263357 Intake tube, 60 L
20 1 264420 Intake tube, 25 L
21 1.10 m 8324008 Base seal
24
2 9971178 O-ring
= Wearing parts
