8
W 350
AUS
2)
Put the nozzle (g. 9 B, 3) onto the gun body and nd the correct position by turning it.
3) Put the air cap onto the nozzle and tighten it using the union nut.
4) Place the container seal from below on the suction tube and slide it over the collar,
while turning the container seal slightly.
5) Insert the suction tube with container seal in the gun body.
13. Maintenance
Air lter
WARNING! Never operate the machine without the air lter; dirt could be
sucked in and interfere with the function of the machine. Disconnect plug
before changing parts.
•
Press both locks and remove the lter cover (Fig. 8).
•
Remove the air lter and replace depending on contamination.
•
Click the lter cover in place again.
•
In order to mount the gun more easily apply lubricating grease (enclosed) liberally
to the O-ring at the gun front part. (Fig. 9, Item 5)
Ventilating hose / Valve
1) Pull the ventilating hose (Fig. 9 A, 13) at the top from the gun body. Screw o the valve
cover (14). Remove the diaphragm (15). Carefully clean all parts or replace in the
event of damage.
2)
Place the diaphragm (Fig. 9 A, 15) with the pin facing upwards on the bottom section
of the valve. Also see the marking on the gun body.
3) Place on the valve cover (Fig. 9 A, 14) and screw it closed.
4)
Place the ventilating hose (Fig. 9 A, 13) on the valve cover and on the nipple at the
gun body.
14. Spare Parts List
Spare Parts List (Fig. 9)
Pos. Designation Order No.
1 Union nut 2362 873
2 Air cap 2361 747
3 Nozzle 2362 878
4 Nozzle seal 0417 706
5 O-ring 2362 875
6 Material volume regulation with spring, complete 0417 910
7 Spray gun front part complete incl. 800 ml container 2361 731
8 Air lter 2370 530
9 Air lter cover 2370 532
