10
W 350
AUS
Problem Cause Remedy
Coating
material causes
"paint tears"
•
Too much coating material
applied.
➞ Reduce the material
volume
Too much fog of
coating material
(Overspray)
•
Distance to the object too large
•
Too much coating material
applied
➞ Reduce distance
➞ Reduce the material
volume
Paint in the
ventilating hose
•
Diaphragm soiled
•
Diaphragm defective
➞ Clean the diaphragm
➞ Replace the diaphragm
17. Technical Data
Technical Data
Max. viscosity 100 DIN-s
Power source 240 V
~
, 50 Hz
Power consumption 550 W
Atomizing output 110 W
Max. ow rate
(water/ Standard Spray attachment) 1210 ml/min
Protection Class I
Sound pressure level* 75 dB (A); Uncertainty K = 4 dB
Sound pressure output* 86 dB (A); Uncertainty K = 4 dB
Oscillation level* < 2.5 m/s²; Uncertainty K = 1.5 m/s²
Weight 1.4 kg
* Measured in accordance with EN 50580:2014
Information about the oscillation level
The specied oscillation level has been measured according to a standard test
procedure and can be used to compare against electric tools.
The oscillation level is also for determining an initial assessment of the vibrational strain.
Attention! The vibration emission value can dier from the specied value when the
electric tool is actually in use, depending on how the electric tool is being used. It is
necessary to specify safety measures to protect the operating personnel. These measures
are based on an estimated shutdown during the actual conditions of use (all parts of the
operating cycle are taken into consideration here, for example periods when the electric
tool is switched o, and, when it is switched on but running without any load).
