6
W 350
AUS
8. Start-up
Before connecting to the mains supply, be sure that the supply voltage is identical with
the value given on the rating plate.
•
Unscrew the container from the spray gun.
•
Aligning suction tube. (Fig. 2)
If the suction tube is positioned correctly, the container contents can be sprayed
without almost any residue.
When working on lying objects: Turn the suction tube forwards. (Fig. 2 A)
Spraying work when working on overhead objects: Turn the suction tube rearwards.
(Fig. 2 B)
•
Set the container on a sheet of paper, pour in the prepared coating material and screw
the container tightly onto the spray gun.
•
Connect the front part with the rear part of the gun (Fig. 3).
•
Put the machine down only on a level, clean surface. Otherwise the machine could tip
over!
•
Press the ON/OFF switch at the device.
•
Pull the trigger. The W 350 has a two-stage trigger. In the rst stage the turbine is started.
If the trigger is pressed further, the material is transported.
9. Adjusting the desired Spray Setting
WARNING! Danger of injury! Never pull the trigger while adjusting the air
cap.
With the union nut (g. 5, 1) slightly unscrewed, turn the air cap (2) to the desired spray
setting position (arrow). Then tighten the union nut.
Fig. 4 A = vertical at jet
for horizontal surfaces
Fig. 4 B = horizontal at jet
for vertical surfaces
Fig. 4 C = circular jet
for corners, edges and hard-to-reach surfaces
10. Adjusting the Material Volume (Fig. 6)
Set the material volume by turning the regulator on the trigger of the spray gun.
- turn to the left lower material volume
+ turn to the right higher material volume
11. Spray Technique
•
The spray result depends heavily on the smoothness and cleanliness of the surface to be
sprayed. Therefore the surface should be carefully prepared and kept free of dust.
•
Cover all surfaces not to be sprayed.
•
It is advisable to test the spray gun on cardboard or a similar surface to nd the correct
