W 950 Flexio/ W 975 Flexio
Wall paint
46
W 950 Flexio/ W 975 Flexio
EN
•
Loosen the pull wire by the adjustment
screw (g. 12, 1). Pull the trigger (g. 12, 2)
disengage the pull wire.
•
Remove the spray head (g. 12, 3) by
pressing the lever (g. 12, 4).
•
Remove the adjustment ring (g. 13, 1)
carefully from the connecting nut (g. 13,
2). Loosen the connecting nut. Remove
the air cap (3), air screen (4), nozzle (5) and
nozzle seal (6) from the spray head.
•
Clean the air cap; air screen, nozzle and
nozzle seal thoroughly.
Attention! Never clean the seals,
nozzle- or air-holes with pointy metal
objects.
•
Remove the suction hose and thoroughly
rinse the suction lter in owing water.
•
If necessary wipe the exterior of the spray
lance.
1

2
3
4

1
2
3
4
5
6
