12.3.2.10 Parameters of the DALI/DSI Master Modules
The table shows the parameterization properties of the DALI/DSI master modules
with asynchronous diagnostic properties.
Table 170: Parameters of the DALI/DSI master modules (DALI)
DALI
Representatives of DALI:
75x-641
Parameterization data length in bytes
Standard parameterization
Structured parameterization
4
8
Parameter
Settings
Description
Scope
Terminal is physically
The I/O module process data is
Module
(optionally) not plugged
• (optionally) set to zero or filtered by the
fieldbus coupler.
plugged
*)
• processed by the I/O module.
Diagnosis
The diagnostic information of the corresponding
channel is
Module
disabled
*)
• not transmitted to the PROFIBUS DP
master.
enabled
• transmitted to the PROFIBUS DP master.
*)
Default settings
12.3.2.11 Parameters of the AS Interface Master
The table shows the parameterization properties of the AS interface master with
asynchronous diagnostic properties and individual parameters.
Table 171: Parameters of the AS interface master (ASI)
ASI
Representatives of ASI:
75x-655
Parameterization data length in bytes
Standard parameterization
Structured parameterization
6
10
Parameter
Settings
Description
Scope
Diagnosis
The diagnostic information of the corresponding
channel is
Module
disabled
*)
• not transmitted to the PROFIBUS DP
master.
enabled
• transmitted to the PROFIBUS DP master.
Mailbox length
The length of the acyclic channel (Mailbox) is
Module
no mailbox
• 0 byte
6 byte
*)
• 6 byte
10 bytes
• 10 bytes
12 bytes
1)
• 12 bytes
18 bytes
1)
• 18 bytes
Cross fading of mailbox
The acyclic channel (Mailbox) can
Module
disabled
*)
• not override the process data.
enabled
• override the process data.
Use of free PI areas
2)
The unused data storage areas for module types
ASI_38D and ASI_46D are
Module
none (with ASi V2.1)
• unused.
Analog values (starting ASi 3.0)
• populated with analog values.
*)
Default settings
1)
Only for process images larger than 12 bytes
2)
Setting for AS-i 3.0 version or higher
12.3.2.12 Parameters of the EnOcean Radio Receiver
The table shows the parameterization properties of the EnOcean radio receiver
with asynchronous diagnostic properties.
