220 Appendix WAGO I/O SYSTEM 750 XTR
750-333/040-000 FC PROFIBUS G2 12MBd XTR
Manual
Version 1.4.0
12.3.2.16 Parameters of the PROFIsafe I/O Modules
The following three tables show the parameterization properties of the
PROFIsafe I/O modules with asynchronous diagnostic properties and individual
parameters.
Table 176: Parameters of the PROFIsafe V1 I/O modules (PSAFE_V1)
PSAFE_V1
Representative of the PSAFE_V1:
750-660/000-001, 750-665/000-001
Parameterization data length in bytes
Standard parameterization
Structured parameterization
17
21
Parameter
Settings
Description
Scope
Terminal is physically
The I/O module process data is
Module
(optionally) not plugged
• (optionally) set to zero or filtered by the
fieldbus coupler.
plugged
*)
• supplied by the I/O module or output to the
periphery.
Diagnosis
The diagnostic information of the corresponding
channel is
Module
disabled
*)
• not transmitted to the PROFIBUS DP master.
enabled
• transmitted to the PROFIBUS DP master.
F_Check_SeqNr
In the F_CRC calculation, the sequence number is
Module
Check
• included.
NoCheck
*)
• not included.
F_Check_iPar
Individual parameters in the F parameter field
Module
NoCheck
*)
• are not checked.
F_SIL
The safety requirement level is
Module
SIL3
*)
• SIL3
F_CRC_Length
The F_CRC has a length of
Module
2-Byte-CRC
*)
• 2 bytes
F_Block_ID
The ID of the F parameter field is
Module
0
*)
• 0
F_Par_Version
The PROFIsafe layer is operated in
Module
V1-mode
*)
• PROFIsafe V1 mode.
F_Source_Add
The F source address can accept the following
values:
Module
1 … 65534
• 1 … 65534
F_Dest_Add
The F destination address can accept the
following values:
Module
1 … 65534
• 1 … 65534
F_WD_Time
The F monitoring time can accept the following
values:
Module
50 … 150
*)
… 10000
• 50 … 10000 ms
*)
Default settings
