WAGO 750-489 User Manual

WAGO-I/O-SYSTEM 750 Process Image 105
750-489 4AI RTD/TC/Strain Gauge Ex i
Manual
Version 1.1.0, valid from FW Version 02
4.9.3 Strain Gauge Bridge Voltage U
d
(±30 mV)
Standard Format
Table 127: Setting Strain Gauge Bridge Voltage U
d
(±30 mV), Standard Format
Voltage [mV]
Numeric Value
1)
Status
Byte,
Hex.
Error
LED
Binary
Range
Hex.
Binary Hex. Dec.
≤ -35.0012
'1000.0000.0000.0000'
0x8000
-32768
0x50
On
Underflow
-35.0
'1000.1110.0001.0001'
0x8E11
-29167
0x41 On Underrange
-30.0012
'1001.1110.0101.0111'
0x9E57
-25001
-30.0
'1001.1110.0101.1000'
0x9E58
-25000
0x00 Off
Nominal
range
-15.0
'1100.1111.0010.1100'
0xCF2C
-12500
15.0
'0011.0000.1101.0100'
0x30D4
12500
30.0
'0110.0001.1010.1000'
0x61A8
25000
30.0012
'0110.0001.1010.1001'
0x61A9
25001
0x42 On Overrange
35.0
'0111.0001.1110.1110'
0x71EE
29167
≥ 35.0012
'0111.1111.1111.1111'
0x7FFF
32767
0x60
On
Overflow
1)
Process values below 0 are represented in binary form as the two’s complement.
S5-FB250 Format
Table 128: Setting Strain Gauge Bridge Voltage U
d
(±30 mV), S5-FB250 Format
Voltage [mV]
Numeric Value
Status
Byte,
Hex.
Error
LED
Binary
Range
Hex.
Binary XFÜ
1)
Hex. Dec.
≤ -35.012
'1000.0000.0000.0
010'
0x8002
-32766
0x50
On
Underflow
-35.0
'1010.0100.1111.0
001'
0xA4E1
-23327
0x41 On Underrange
-30.012
'1011.0001.1101.1
001'
0xB1D9
-20007
-30.0
'1011.0001.1110.0
000'
0xB1E0
-20000
0x00 Off
Nominal
range
-15.0
'1101.1000.1111.0
000'
0xD8F0
-10000
15.0
'0010.0111.0001.0
000'
0x2710
10000
30.0
'0100.1110.0010.0
000'
0x4E20
20000
30.012
'0100.1110.0010.1
001'
0x4E29
20009
0x42 On Overrange
35.0
'0101.1100.0010.0
001'
0x5B21
23329
≥ 35.012
'0111.1111.1111.1
010'
0x7FFA
32762
0x60
On
Overflow
1)
Status bits: X= not used, F= error, Ü= overflow
