64 Process Image WAGO-I/O-SYSTEM 750
750-489 4AI RTD/TC/Strain Gauge Ex i
Manual
Version 1.1.0, valid from FW Version 02
4.5.3.5 TC Type E – Standard Format/Fahrenheit
Table 55: TC Type E Setting – Standard Format/Fahrenheit
Temperature
[°F]
Numeric Value
1)
Status
Byte,
Hex.
Error
LED
Range
Binary Hex. Dec.
≤ -373.1
'1000.0000.0000.0000'
0x8000
-32768
0x50
On
Underflow
-373.0
'1111.0001.0110.1110'
0xF16E
-3730
0x41 On Underrange
-328.1
'1111.0011.0010.1111'
0xF32F
-3281
-328.0
'1111.0011.0011.0000'
0xF330
-3280
0x00 Off
Nominal
range
1832.0
'0100.0111.1001.0000'
0x4790
18320
1832.1
'0100.0111.1001.0001'
0x4791
18321
0x42 On Overrange
1877.0
'0100.1001.0101.0010'
0x4952
18770
≥ 1877.1
'0111.1111.1111.1111'
0x7FFF
32767
0x60
On
Overflow
1)
Process values below 0 are represented in binary form as the two’s complement.
4.5.3.6 TC Type E – S5-FB250 Format/Fahrenheit
Table 56: TC Type E Setting – S5-FB250 Format/Fahrenheit
Temperature
[°F]
Numeric Value
Status
Byte,
Hex.
Error
LED
Range
Binary XFÜ
1)
Hex. Dec.
≤ -374.0
'1000.0000.0000.0
010'
0x8002
-32766
0x50
On
Underflow
-373.0
'1111.0100.0101.1
001'
0xF459
-2983
0x41 On Underrange
-329.0
'1111.0101.1011.1
001'
0xF5B9
-2631
-328.0
'1111.0101.1100.0
000'
0xF5C0
-2624
0x00 Off
Nominal
range
1832.0
'0011.1001.0100.0
000'
0x3940
14656
1833.0
'0011.1001.0100.1
001'
0x3949
14665
0x42 On Overrange
1877.0
'0011.1010.1010.1
001'
0x3AA9
15017
≥ 1878.0
'0111.1111.1111.1
010'
0x7FFA
32762
0x60
On
Overflow
1)
Status bits: X= not used, F= error, Ü= overflow
