168 Configuring in the Web-Based Management System (WBM) WAGO-ETHERNET-Zubehör 852
852-1305 8/4-Port 100BASE-T/1000BASE-SX/LX
Manual
1.1.0
Table 64: WBM “GARP VLAN Registration Protocol” Page – “GVRP Timer” Tab
GARP Timer Settings
Parameters
Default
Description
Port
From:
1
Select a port or port range in the selection box to
configure the GARP timer.
To:
1
Select a port or port range in the selection box to
configure the GARP timer.
Join Time
20
Enter the maximum time in milliseconds that the
interface waits before sending VLAN messages.
Leave Time
60
Enter the maximum time in milliseconds that the
interface waits after receiving a “Leave Message”
before the interface leaves the VLAN specified in
the message.
Leave All Time
1000
Enter the time interval in milliseconds after which
the Leave All messages are sent to interfaces. Leave
All messages can help to update information about
current GVRP VLAN subscriber information in the
network.
GARP Timer Status
Parameters
Default
Description
Port
1 … 10
This column displays the port numbers.
Join Time
This column displays the Join Time.
Hold Time
10
This column displays the Hold Time.
Leave Time
This column displays the Leave Time.
Leave All Time
This column displays the Leave All Time.

WAGO 852-1305 Specifications

General

Product Type	Managed Ethernet Switch
Number of Ports	5
Switching Capacity	1 Gbps
Power Supply	24 VDC
Port Type	RJ45
Protection Class	IP20
Operating Temperature	-40 to 70 °C
