Design of the Process Data for PROFIBUS-DP
WAGO-I/O-SYSTEM 750
Bus System
5.2.24 Serial Interface
750-650, 750-651, 750-653 (default setting)
Process Image Length in [Byte]
Register communication possible Input Output
Yes (not possible) - -
No 4 4
Mapping
Data format MOTOROLA INTEL
I/O area Input Output Input Output
S C S C
D0 D0 D0 D0
D1 D1 D1 D1
D2 D2 D2 D2
D3 (6) D3 (6) D3 (6) D3 (6)
Channel 1
D4 (6) D4 (6) D4 (6) D4 (6)
750-650/003-0??, 750-651/003-0??, 750-653/003-0?? (settable)
Process Image Length in [Byte]
Register communication possible Input Output
Yes 4/6 4/6
No (not possible) - -
Mapping
Data format MOTOROLA INTEL
I/O area Input Output Input Output
S0 C0 S0 C0
D0 D0 D0 D0
D1 D1 D1 D1
D2 (4, 6)
*2)
D2 (4, 6)
*2)
D2 (4, 6)
*2)
D2 (4, 6)
*2)
D3 (6)
*2)
D3 (6)
*2)
D3 (6)
*2)
D3 (6)
*2)
Channel 1
D4 (6)
*2)
D4 (6)
*2)
D4 (6)
*2)
D4 (6)
*2)
*2)
The numbers in brackets stand for the projected data length.
