13.3.5.6 SSI Transmitter Interface Modules
750-630, (and all variations)
The process image of the / 003-000-variants depends on the parameterized
operating mode!
The operating mode of the configurable /003-000 I/O module versions can be
set. Based on the operating mode, the process image of these I/O modules is
then the same as that of the respective version.
The above SSI Transmitter Interface modules have a total of 4 bytes of user data
in the Input Process Image, which has 2 words mapped into the image.
Word alignment is applied.
Table 453: SSI Transmitter Interface Modules
Input Process Image
Instance
Byte Destination
Description
High Byte
Low Byte
n
D1
D0
Data bytes
n+1
D3
D2
The specialty modules represent 2x2 bytes input data and seize 2 Instances in
Class (0x67).
750-630/000-004, -005, -007
In the input process image, SSI transmitter interface modules with status occupy
5 usable bytes, 4 data bytes, and 1 additional status byte. A total of 3 words are
assigned in the process image via word alignment.
Table 454: SSI Transmitter Interface I/O Modules with an Alternative Data Format
Input Process Image
Instance
Byte Destination
Description
High Byte
High Byte
n
-
S
not used
Status byte
D1
D0
Data bytes
D3
D2
The specialty modules represent 1x6 bytes and seize 1 Instance in Class (0x67).
