WALKER FILTRATION PD015 - Page 13

13
Pro Dry Instruction Manual | Walker Filtration | www.walkerltration.com
Section 3: Mechanical Installation
13
13
Figure 3.7: Level ground
13
13
Figure 3.8: Drainage (all tubing should be secured up to the point of drain to prevent whipping during discharge)
