Walker MS (13 HP) - Page 38

Operating Instructions
34
PTO and Blade
Gear Drive
Rear Discharge
Mower Deck
Deck
Discharge Chute
Blower
Body Chute
Assembly
Grass Catcher
Catcher
Door Spring
Catcher
Door
Exhaust
Deflector
Exhaust Screen
(Removable)
Catcher Door
Safety Latch
Grass-Pak
®
Vane Switch
“Full” Signal
Horn
Actuator
Rod
Powerfil
®
Drive Motor
Dump Handle
Powerfil
®
Delivery Spout
Delivery
Chute
Shear Pin
Shear
Bolt
PTO
Clutch
GHS Flow and Components
GRASS HANDLING SYSTEM (GHS)
GHS Model Only
