19
(888) 253-0777
IMPORTANT: The LEFT and RIGHT Struts and Casters (B) must match the
LEFT and RIGHT Legs (C). If they are not installed correctly the wheelchair
will be extremely wobbly. We refer to L and R as if you are in the wheelchair.
A
H
B
C
E
F
G
D
THE PACKAGE CONTAINS:
Assembling Fully Supportive Wheelchair
Here is the video if you have purchased the quad wheelchair:
https://www.handicappedpets.com/
instructional-videos-medium-fully-supportive-dog-wheelchair/
The front leg will arrive already installed on the front extender but will
be loose. Using the Gold Screws, position the front leg on the Front
Extender. Do this by lining up the holes on the inside of the front leg and
the holes on the inside of the Front Extender
Tighten gold screws
Front leg
Extender
Step 1:
Positioning the Front Leg on the Front Extender
In the Package
The Front Wheel Attachment is easy to assemble and snap into the wheel-
chair. You will need a Phillips head screwdriver.
The package contains:
To Next Page
