Wallgate WDC100 - Page 24

Revision 15
24
Main Menu Item
Sub Menu 1
Sub Menu 2
Available Options
Default
Value
Cell Water
Settings
Basin cold outlet run
time
Basin Cold Cycle
Time
1 to 999 Seconds
10
Seconds
Basin hot outlet run
time
Basin Hot Cycle
Time
1 to 999 Seconds
10
Seconds
Permitted number of
basin activations
Basin Cycle
Activations
1 to 100 Activations
10
Activations
Time period of a basin
activation cycle
Basin Cycle Period
15 to 1440 Minutes
60 Minutes
Basin lockout time
Basin Lockout Time
15 to 1440 Minutes
60 Minutes
Shower outlet run time
Shower Cycle Time
1 to 999 Seconds
60
Seconds
Permitted number of
shower activations
Shower Cycle
Activations
1 to 100 Activations
4
Activations
Time period of a
shower activation cycle
Shower Cycle
Period
15 to 1440 Minutes
60 Minutes
Shower lockout time
Shower Lockout
Time
15 to 1440 Minutes
60 Minutes
WC Full cycle
W.C. Full Cycle
Time
1 to 999 Seconds
2.0
Seconds
WC Reduced cycle
W.C. Reduced time
1 to 999 seconds
0.5
seconds
Oli Travel (see below)
Oli Travel
1 to 100 or OFF
100
This must not be
set below the
default value of
100.
Permitted number of
WC activations
W.C. Cycle
Activations
1 to 100 Activations
4
Activations
Time period of a WC
activation cycle
W.C. Cycle Period
15 to 1440 Minutes
15 Minutes
WC lockout time
W.C. Lockout Time
15 to 1440 Minutes
15 Minutes
WC cistern refill time
W.C. Refill Time
1 to 999 Seconds
30
Seconds
Oli Travel
The default setting must be adjusted when a direct flush valve (Model DFKIT03)
is used to flush the WC instead of a cistern tank with integral flush valve
(i.e.; model CIST19-ELEC).
For operation of the direct flush valve model DFKIT03 the Oli travel setting must
be set to “OFF” and the “WC full flush cycle time” shall need to be adjusted from
2 seconds to the required time for the DFKIT03 valve to be open to deliver a 6
litre per full flush.
If a dual flush option is applicable, then the WC Reduced cycle time” shall also
require adjustment for the DFKIT03 direct flush valve. As a guide, typical cycle
times for the direct flush valve DFKIT03 are 4 seconds for full flush and 2.5
seconds for the reduced flush, but this is dependent on the flow characteristics on
the plumbing system design, including pipe size.
