0,08”
RESPONSE TIME
10%
100 bar
90%
95%
105%
Pressure
Time (”)
(% DP)
Response time
1450 psi
Spring nr. 3 (blue band)
0
100
200
300
400
0 10 20 30
Flow
Pressure
(l/min)
(bar)
(psi)
4500
3000
1500
VS relief valve
Services valves
Performance data
Adjustment type
G: with screw H: valve set and locked
VST: valve blanking plug
P
A1 B1 A2 B2
T
It’s suggested for flow up to 25 l/min -- 6.6 US gpm, and it’s mounted on parallel body to limitate the pressure, at lower value than
main relief valve (min. gap 20 bar -- 290 psi ), on downstream section.
It’s in parallel with flow trough and it works only with single operation.
120
Adjustment type (G, H)
VS5 ( G 3 -- 100 )
Pressure setting in bar
(standard 100 bar / 1450 psi)
100
1450
1750
Wrench 10
9.8 Nm / 7.2 lbft
Wrench 17
24 Nm / 17.7 lbft
Wrench 19
24 Nm / 17.7 lbft
32.5
Max.
1.28
Allen wrench 3
4
Allen wrench 6
42 Nm / 31 lbft
0.16
2 4 6
(US gpm)
SD5
44 DAT003A
