3.0 TECHNICAL INFORMATION
2
EXT.SBB-HFF.--.M.A.0219.EN Issue: A
02.19
15
SBB-HFF
MODEL S:
HOPPER WITH REMOVABLE FRAME
- SBB._.125.S
Athough it is identical as regards design and use, the di󰀨erence lies in the size of the FIBCs which can be
accepted.
These comprise:
- an unloading hopper with seal (made of food- grade material for hopper in stainless steel).
- a supporting tubular frame having size and thickness suitable to ensure sturdiness and solidity.
- a removable frame which makes it possible to adapt the Unloader for use with FIBCs of di󰀨erent heights.
- cross with pegs for hooking FIBC harness and tubular elements for lift truck forks. (for frame in Stainless
Steel 304, the lifting cross is in Carbon Steel galvanized painted in RAL 1004)
ITEM DESCRIPTION
1
Lifting cross
painted in RAL 1004
2
Vibrating Hopper
in Mild Steel painted RAL 7001
in Stainless Steel 304 glass blasted
3
Frame support
in Mild Steel painted RAL 7001
in Stainless Steel 304 glass blasted
4
Hopper Seal
Hopper in Mild Steel , Seal Black , counterange galvanized
Hopper in Stainless Steel 304, Seal White, counterange Stainless Steel 304
5 Access Door with microswitch predisposition
6 Outlet cone 273 mm
7 Adjustable frame (100mm pitch)
8 Petals Pneumatic Kit
1
4
2
3
5
6
8
7
